Key Features

• Encodes 2ch USB audio to Dante® digital signal
• Decodes a Dante® digital signal to 2ch USB audio
• Selectable USB audio between USB Type-B and USB-C inputs
• Compliant with USB Audio Device Class Specification v1.0
• Supports 44.1, 48, & 96KHz sample rates @ 24 Bit
• Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)
• Supports AES67 RTP audio transport
• Features Class 3 IEEE 802.3af PoE for powering of the product from a PoE switch
• Supports power via 5V USB for when network switch does not support PoE*Dante® is a registered trademark of Audinate Pty Ltd

Specifications

• Audio Input Connectors: 1x RJ45, female (100Mbps Dante® network), 1x USB Type B female, 1x USB Type C female
• Audio Output Connectors: 1x RJ45, female (100Mbps Dante® network), 1x USB Type B female, 1x USB Type C female
• Casing Dimensions (W x H x D): 120mm x 26mm x 47mm
• Shipping Weight: 0.3kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature : -4°F to 140°F (-20°C to 60°C)
• Power Supply: Class 3 IEEE 802.3af PoE, or 5V USB

Box Contents

• 1x DA11USB
• 1x USB-A to USB-B cable - 1m
• 1x USB-C to USB-C cable - 1m
• 1x Quick Reference Guide
