Key Features

• Suggested OEM equipment connector due to LC front compatibility
• Designed as feedthrough with automatic sealing shutter
• Shutter with silicone gasket protects optical connection from dust and dirt
• Accommodates standard LC connectors on the rear for simple installation
• Connection on the front side either by rugged optical CON or standard LC connector
• The low cost of the chassis connector makes it a viable alternative to traditional connectors in fixed installations
• IP65 ingress protection in mated condition with SCDP-*
• Color coding with SCDP-* according to ANSI/TIA-568.3-D Standard:Multimode - blackSingle mode PC - blueSingle mode APC - green

Technical Information

Product

• Gender: Female

Electrical

• Contact resistance: < 7 mΩ
• Dielectric strength: 1.5 kVdc
• Insulation resistance: > 2 GΩ (initial)
• Rated current per contact: 6 A
• Rated voltage: < 50 V (1)

Mechanical

• Insertion force: < 45 N
• Withdrawal force: < 45 N
• Lifetime (typ.): 5000 mating cycles
• Locking force: 1000 N
• Locking device: Push-Pull
• Mounting direction: Front mounting
• Chassis shape: D

Material

• Contacts: Bronze (CuSn6)
• Insert: Polyamide (PA 6, PBT 30 % GR, PBT 50 % GR)
• Shell: Zinc diecast (ZnAl4Cu1)
• Shell plating: Black chromium
• Split sleeve: Ceramics

Environmental

• Temperature range: -40 °C to +75 °C
• Protection class: IP65 in mated condition in combination with SCDP-*

Optical

• Insertion loss: < 0.4 dB / connection
• Optical connector: LC-Duplex Feedthrough
