Key Features:

• High quality electrical and electronical component from the renowned brands
• Circuit protection withminiature circuit breakers (MCB)
• High quality assembly in EU
• Attractive price / value ratio

Applications:

• Markets:Professional audio esp. amp rack wiring / lighting / video wall
• Mobile applications:Festivals, live events. Control panels / rooms.
• Semi-permanent applications:Theaters, studios, fairs. Control panels /rooms.

Technical Specifications:

Product

• Input device: 1x CEE32A 5P red (front)
• Daisy chain: 1x CEE32A 5P red (daisy chain) front
• Output device: 6 x powerCON® TRUE1® TOP Out & 3 x Schuko Typ F Out

Electrical

• Circuit protection: 3x MCB 1pol C16
• Phase control indicator: L1, L2, L3, green
• Rated voltage: 415V/AC, 50Hz
• Rated Current CEE Socket: 415V | Schuko Socket & powerCON® TRUE1® TOP: 230V 16A

Mechanical

• Weight: 3,8kg
• Type of construction: 19“ Housing 2 HE, 1,5TE
• Dimensions: 483 x 88 x 104 mm (without fittings)

Material

• Housing: Metal
• Color: black

Environmental

• Protection class: IP20
• Temperature range: -5 to +40 °C
