Key Features:

• Extreme robust and safe EASYLEN® housing with leather grain texture
• Mains receptacles CEE16A IN & daisy chaining and highly reliable NEUTRIK® powerCON® TRUE1® TOP OUT
• Flame retardant (UL94-V2) and non-conductive housing material
• High outdoor protection (IP65, IK, ..)
• Light weight, compact and stackable housing design
• Versatile mounting options

Applications:

• Main markets: Professional video walls, event lighting, pro-audio
• Mobile application: Festivals, live events
• Semi-permanent applications: Theaters, studios

Technical Specifications:

Product

• Input device: 1xCEE16-5
• Output device: 6x powerCON® TRUE1® TOP
• Daisy chaining: 1xCEE16-5

Electrical

• Contact resistance / protection class Dielectric strength: Protection class II
• Dielectric strength: 0,5 kV / mm
• Rated voltage: 400V AC
• Rated Current: 16A
• Number of electrical contacts: 4 + PE
• Phases: multi-phase (3+N+PE)

Mechanical

• Conductor cross section: 2,5 mm²
• Mounting options: Truss clip, truss clamp, mounting wholes for pegging or suspension
• Weight: 2.1 kg
• Dimensions: 528.6 x 92 x 117.2 mm

Material

• Housing: Easylen
• Color: black

Environmental

• Protection class: IP65
• Temperature range: -25 °C bis +40 °C
• Standards compatibility: UL94-V2
