Technical Specifications

Description

Laser

  • Source: 24000mW diode
  • Red power/wavelength: 6000mW/638nm
  • Green power/wavelength: 8000mW/520nm
  • Blue power/wavelength: 10000mW/450nm
  • Color mixing: RGB
  • Safety class: 4
  • Modulation: Analogue

Scanner

  • Scan system: ILDA 40K pps
  • Scanning angle: ±30°

Control & Programming

  • Control protocols: ILDA, DMX, Auto, Sound, Master-slave
  • Internal patterns: 256
  • Control channels: 17 CHs

Electrical

  • Input voltage: AC100-240V 50/60Hz
  • Power consumption: 250 watts

Connections

  • DMX Connections: 3 pin XLR In/Out male and female
  • Power connections: PowerCon In

Physical

  • Dimensions: 420 x 410 x 280 mm
  • Net weight: 39 Kg
  • Color: Black
  • IP rating: 20
  • Operating temperature: 0°C/40°C
