Adamson VGo Subwoofer - Large-Format 1x 21.5" SD21.5 & 1x 18" SD18, Cardioid Bass Reflex

New

Adamson VGo Subwoofer - Large-Format 1x 21.5" SD21.5 & 1x 18" SD18, Cardioid Bass Reflex

Name: Adamson VGo Subwoofer - Large-Format 1x 21.5" SD21.5 & 1x 18" SD18, Cardioid Bass Reflex
Brand: Adamson
SKU: 993-0003

Brand: Adamson

Categories: Passive Subwoofers

SKU: 993-0003

The VGo is a single-driver cardioid subwoofer in Adamson's Vergence Group, pairing one front-loaded 21.5" SD21.5 transducer with one rear-loaded 18" SD18 directional driver. On-board Class-D amplification and built-in rigging mean one less amp rack to haul, reproducing down to 27 Hz at 111 kg per cabinet.

Product variants

Pairs well with

Adamson VGo Subwoofer - Large-Format 1x 21.5" SD21.5 & 1x 18" SD18, Cardioid Bass Reflex

Technical Specifications

Description

Frequency Range (+/-3 dB): 27 Hz – 100 Hz

Maximum Peak SPL**: 142 dB

Components LF: Front: SD21.5 Kevlar® Neodymium Driver, Rear: SD18 Kevlar® Neodymium Driver

Rigging: Autolock Rigging System

Connection: 2x etherCON™ (passive continuity when powerless), Analog XLR3 in & thru, powerCON TRUE1 TOP in & thru

Height Front (mm / in): 660 / 26

Width (mm / in): 1219 / 48

Depth (mm / in): 803 / 31.6

Weight (kg / lbs): 111 / 245

Input Voltage: 85 – 265 V

Current Draw at 230 V: 1 A rms idle, 7.4 A rms long-term, 42.4 A max peak

Amplification: 2-Channel Onboard Class-D, SMPS

Processing / Network: User-accessible DSP with AVB Milan audio streaming

Total Burst Power: 12 kW

** Measured with 12dB crest factor pink noise at 1m

Downloads

VGo_Tech_Specs.pdf
