Adamson VGx - Full-Range Line Array

Name: Adamson VGx - Full-Range Line Array
Brand: Adamson
SKU: 976-0002

Brand: Adamson

Categories: Line Arrays

SKU: 976-0002

VGx is the largest, most powerful full-range addition to Adamson's Vergence Group. Three M140 mid-range transducers and three NH3-V-16 HF drivers sit on a new coaxial assembly with 80-degree coverage, reaching 153 dB max SPL with 22 dB rear rejection. On-board 18kW Class-D amplification, DSP and networked audio, at 118 kg per cabinet.

Product variants

Pairs well with

Adamson VGx - Full-Range Line Array

Technical Specifications

Description

Components MF:

3x M140 Kevlar Compression Driver

Components HF:

3x NH3-V-16 Compression Driver, 3° coaxial assembly

Components LF (front-firing):

1x SD18 18" Driver, dual wound voice coil

Components (side-firing, directional):

1x ND13-S 13" Kevlar Neodymium Driver

Maximum Peak SPL:

153 dB

Nominal Horizontal Coverage:

80°

Rear Rejection:

22 dB (cardioid mode); omni preset also available

Amplification:

18kW peak Class-D, 6 channels (2 full-bridge LF, 4 half-bridge MF/HF)

Processing:

Onboard DSP, networked audio

Rigging:

Integrated rigging system

Height (mm):

Width (mm):

1460

Depth (mm):

Weight (kg):

Downloads

VGx_-_Tech_Specs.pdf
