Key Features
• 4K multi-format multi-view presentation switch
• Features HDMI, USB-C, AirPlay, Miracast®, Chromecast® and Blustream wireless dongle support which can be switched to dual HDMI outputs
• Dual HDMI output supports mirror or desktop extension for managed source control within advanced video conferencing setups
• Multiview presentation with up to 5 concurrent video signals and configurable screen layout
• In-built video scaler with Main output timing up to 4K 60Hz 4:4:4, and Sub output timing up to 1080p 60Hz
• USB-C connection for BYOM, with DP, USB, 1Gbps network and up to 65W power charging
• HDMI & USB Type B connection for BYOM, with USB and 1Gbps network via USB Type B connection
• Localised 2.4G/5G Wi-Fi access point to host AirPlay, Miracast® and Chromecast® local point-to-point mode (up to 1080p 30Hz)
• Dual LAN connection for integration to existing network infrastructures
• Supports USB camera and MIC over t up (1080p 30Hz)
• Supports USB touch-back feature via WMF-USBC-D and WMF-HDMI-D dongles and Miracast®*
• Audio breakout to balanced / unbalanced analogue L/R audio
• Web interface module for control and configuration of switch
• OSD control with preview function
• Whiteboard canvas and screen overlay annotation feature
• Control via front panel, RS-232 and TCP/IP with manual, or auto source selection

Please note: *Miracast® touch-back compatibility subject to Windows features


Product Specifications
• Video Input Connectors: 1 x HDM Type A, female, 1 x USB Type C, female,
• Video Output Connectors: 2 x HDMI Type A, 19-pin, female
• Audio Output Connectors: 5-Pin Phoenix connector (2ch balanced/un-balanced analogue audio)
• RS-232 Serial Port: 1 x 3-pin Phoenix connector
• TCP/IP Control: 2 x RJ45, female (1000Mbps x2)
• USB Connector: 3 x USB 3.0 Type A female, 1 USB 3.0 Type B female
• USB Pairing Connector: 1 x USB 2.0 Type A female, 1 x USB 2.0 Type C female
• Wi-Fi Antenna Connections: 3 x SMA, female connector, MIMO antennas (2.4G & 5G, WIFI IEEE 802.11 b/g/n/ac up to 1200Mbps)
• Wi-Fi Encryption: AES WPA PSK, WPA2 PSK
• Wi-Fi Specification for Europe only:
- 2.4GHz EIRP < 20dBm
- 5.150~5.250GHz EIRP < 23dBm
- 5.725~5.850GHz EIRP < 13.98dBm
• Dimensions (W x H x D): 220mm x 27mm x 161mm (excluding antennas)
• Shipping Weight: 1.5kg
• Operating Temperature: 0°C to 45°C (32°F to +113°F)
• Storage Temperature: -20°C to 70°C (-4°F to +158°F)
• Power Supply: 24V/5A DC

Box Contents
• 1 x WMF72-V2
• 1 x 24V/5A DC Power Supply
• 1 x 3-pin Phoenix Connector (RS-232)
• 1 x 5-pin phoenix connector (audio)
• 3 x Antenna
• 1 x Mounting Kit
• 1 x Quick Reference Card
