Technical Specifications

Description

Performance

  • Frequency Range (-10 dB): 60 Hz – 20 kHz
  • Nominal Impedance: 8 ohms
  • RMS Power Handling: 5 / 10 / 15 W
  • On-axis Sensitivity (1 W / 1 m): 90 dB SPL
  • Transformer Taps: 70 V: 2.5 / 5 / 7.5 W
  • 100 V: 5 / 10 / 15 W

Connectors

  • Audio Input Connector: Terminal Strip
  • Audio Output Connector: Terminal Strip

Enclosure

  • Enclosure Material: Plastic
  • Color: White
  • Dimensions ( H x W x D ):
  • 80 x 80 x 230 mm
  • Net Weight:
  • 1.5 kg
