Key Features:

• Pixel Pitch (mm): 2.6-5.2/15.625
• Maximum Brightness (cd/m²): ≤ 4500
• Curved: 45° 1/4
• Refresh Frequency (Hz): ≤ 3840

Technical Specifications

1. Model-Specific Specifications

Model: P2.6-5.2-100×50

• Order Number (SKU) - Straight Panel: VT-ID-P260-520-1000X500-CT
• Order Number (SKU) - Curved Panel: VT-ID-P260-520-1000X500-CV45-CT
• Pixel Pitch: 2.6 - 5.2 mm
• Cabinet Resolution: 384 × 96

Model: P3.9-7.8-100×50

• Order Number (SKU) - Straight Panel: VT-ID-P391-781-1000X500-CT
• Order Number (SKU) - Curved Panel: VT-ID-P391-781-1000X500-CV45-CT
• Pixel Pitch: 3.9 - 7.8 mm
• Cabinet Resolution: 256 × 64

Model: P7.8-100×50

• Order Number (SKU) - Straight Panel: VT-ID-P781-1000X500-CT
• Order Number (SKU) - Curved Panel: VT-ID-P781-1000X500-CV45-CT
• Pixel Pitch: 7.8 mm
• Cabinet Resolution: 128 × 64

Model: P10.42-100×50

• Order Number (SKU) - Straight Panel: VT-ID-P10-1000X500-CT
• Order Number (SKU) - Curved Panel: VT-ID-P10-1000X500-CV45-CT
• Pixel Pitch: 10.42 mm
• Cabinet Resolution: 96 × 48

Model: P15.625-100×50

• Order Number (SKU) - Straight Panel: VT-ID-P15-1000X500-CT
• Order Number (SKU) - Curved Panel: VT-ID-P15-1000X500-CV45-CT
• Pixel Pitch: 15.625 mm
• Cabinet Resolution: 64 × 32

2. Shared Specifications (All Models)

Display & Image Output

• LED Configuration: SMD1921
• Maximum Brightness: ≤ 4500 cd/m²
• Refresh Frequency: ≤ 3840 Hz
• Scan Ratio: 1/8
• Viewing Angle (Vertical / Horizontal): 140° / 140°
• Transparency: 62%

Panel Features & Physical Build

• IP Rating: Indoor
• Cabinet Material: Die-Cast Aluminum
• Serviceability: Rear
• Curving Concave: 45° 1/4
• Curving Convex: 45° 1/4

Operational Environment

• Operational Temperature: -20°C ~ 60°C
• Operational Humidity: 10% ~ 60% RH

Power Consumption

• Maximum Power Consumption: 600 Watts/m²
• Average Power Consumption: 200 Watts/m²

Size & Weight

• Cabinet Size (LxWxH): 1000 x 500 x 75 mm
• Module Size (LxW): —
• Cabinet Weight: 6 Kg
