Key Features:

• Pixel Pitch (mm): 2.976/4.81
• Maximum Brightness (cd/m²): ≤ 4500
• Curved: 5° / 10°
• Refresh Frequency (Hz): ≤ 3840

Technical Specifications:

1. Model-Specific Specifications

Model: P2.976-50×50

• Order Number (SKU) - Straight Panel: VT-OD-P297-500×500-LT-WP
• Order Number (SKU) - Curved Panel: VT-OD-P297-500×500-C-LT-WP
• Pixel Pitch: 2.976 mm
• Cabinet Resolution: 168 × 168

Model: P3.91-50×50

• Order Number (SKU) - Straight Panel: VT-OD-P391-500×500-LT-WP
• Order Number (SKU) - Curved Panel: VT-OD-P391-500×500-C-LT-WP
• Pixel Pitch: 3.91 mm
• Cabinet Resolution: 128 × 128

Model: P4.81-50×50

• Order Number (SKU) - Straight Panel: VT-OD-P481-500×500-LT-WP
• Order Number (SKU) - Curved Panel: VT-OD-P481-500×500-C-LT-WP
• Pixel Pitch: 4.81 mm
• Cabinet Resolution: 104 × 104

2. Shared Specifications (All Models)

Display & Image Output

• LED Configuration: SMD1921
• Maximum Brightness: ≤ 4500 cd/m²
• Refresh Frequency: ≤ 3840 Hz
• Scan Ratio: 1/16
• Viewing Angle (Vertical / Horizontal): 140° / 140°
• Transparency: Solid

Panel Features & Physical Build

• IP Rating: Outdoor
• Cabinet Material: Die-Cast Aluminum
• Serviceability: Front / Rear
• Curving Concave: 5° / 10° (for curved models)
• Curving Convex: 5° / 10° (for curved models)

Operational Environment

• Operational Temperature: -20°C ~ 60°C
• Operational Humidity: 10% ~ 60% RH

Power Consumption

• Maximum Power Consumption: 800 Watts/m²
• Average Power Consumption: 250 Watts/m²

Size & Weight

• Cabinet Size (LxWxH): 500 x 500 x 75 mm
• Module Size (LxW): 250 x 250 mm
• Cabinet Weight: 8 Kg
