Technical Specifications

Description

SPECIFICATION

  • Input Voltage: US Model : AC 100 – 120V, 50 / 60 Hz 15.5A
    EU Model : AC 220 – 240V, 50 / 60 Hz 8.0A
  • Rated Power: 1820 W
  • Light Source: 27 X 8W LED ( 5-in-1 LED)
  • Warm-Up Time: 14 Minutes (approx)
  • Fluid Consumption: 400 ml/min (100% Output)
  • Fluid Tank Capacity: 6 Liters (1.59 Gallon)
  • Compatible Fluid: Antari FLC Super Light Fog Fluid
  • Ambient Temp. Range: 0°C – 40°C (32°F – 104°F)
  • Output: 10 Meters Height
  • Control Methods: Manual
    Timer
    DMX 512
    Master / Slave
    Wireless
    Wireless DMX (Optional)
  • DMX Channels: 10 / 15 / 25 Channel
  • Interface: Neutrik powerCON TRUE 1 (Power)
    XLR 3-Pin & 5-Pin (DMX)
  • Included Accessories: W-2 Wireless Transmitter
  • Optional Accessories:TIMO-WTR-90 2in1 W-DMX Expansion Module
    M-9-HB Omega Hanging Bracket(*Note : One M-9 requires 2 pcs M-9-HB.)
  • Dimension: L393 W321 H420 mm
    L15.47 W12.63 H16.53 inch
  • Weight: 25.0 kg
    55.10 lbs
