Key Features:

• Reduction of cabling volume and effortdue to multicore Socapex 419 compatible connector. Even more reduction of cabling due to 12x Outs
• Extremely rugged Easylen® housing:IP65, high IK, self-closing caps, lateral connector protection, flame retardant & non-conductive housing material
• Easy transport & handling:stackable, lightweight, fully lockable
• Versatile mounting options:pegs, suspension, truss clamp

Applications:

• Markets: Professional video wall / lighting / audio
• Mobile application: Festivals, live events
• Semi-permanent applications: Theaters, studios

Technical Specifications:

Electrical

• Contact resistance / protection class: Protection class II
• Dielectric strength: 0,5 kV / mm
• Rated voltage: 250V AC
• Rated Current: 16A
• Number of electrical contacts: 2 + PE
• Phases: single-phase

Mechanical

• Dimensions: 225 x 167 x 144 mm
• Conductor cross section: 2,08 mm²
• Mounting options: Truss clamp (M10), mounting wholes for pegging or suspension
• Type of construction: Stackable

Material

• Housing: Easylen
• Color: Black

Environmental

• Flammability acc. to UL 94: V-2
• Protection class: IP65 with Socapex 419 in mated condition
• Temperature range: -25 °C to +40 °C
