Key Features

• Features 2 x HDMI inputs which can be switched to a single HDMI output
• Auto-switching (HPD sensing) capabilities can be enabled / disabled*
• Supports full HDMI 2.0 specification 4K UHD video (4K @60Hz 4:4:4)
• HDCP 2.2 compliant
• Supports 3D signal display
• Supports CEC bypass (Consumer Electronics Control)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• HDMI audio breakout to analogue L/R audio and Coaxial digital outputs concurrently
• Control via front panel and IR (remote control included)
• Advanced EDID management* Auto switching only available on units with serial no. 70522400001 or above

Specifications

• Video Input Connectors: 2 x HDMI Type A
• Video Output Connectors: 1 x HDMI Type A
• Audio Output Connectors: 1 x RCA (SPDIF) & 1 x Analogue audio L/R (3.5mm stereo jack)
• IR Input Ports: 1 x 3.5mm stereo Jack
• Product Dimensions (W x D x H): 196 x 104 x 32mm (with connections)
• Product Dimensions (W x D x H): 196 x 94 x 23mm (without connections)
• Product Weight: 0.45kg (excluding accessories)
• Carton / Box Dimensions (W x D x H): 295 x 155 x 80mm
• Shipping Weight: 0.8kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Power Supply: 5V/2A DC

Box Contents

• 1 x SW21AB-V2
• 1 x SW21 Remote
• 1 x 5V/2A DC Power Supply
• 1 x User Manual
