Technical Specifications

Description

Ports & Performance

  • Total Ports: 16
  • Copper Ports: 8 × 10GBASE-T (100M / 1G / 10G)
  • Fiber Ports: 8 × SFP+ (1G / 10G)
  • Switching Capacity: 320 Gbps
  • PoE: N/A

Hardware & Design

  • Form Factor: 1U half-width, stackable
  • Power Supply: 250W modular PSU included (APS250W)

Management & Connectivity

  • Out-of-Band Management: 1 × 1G Ethernet
  • Console Ports: RJ45 RS232 and Mini-USB
  • USB Port: For storage, logs, configuration or image files
  • Management Platform: NMS300 (single-pane-of-glass, mass configuration support)

Key Features

  • All 10G ports are independent and 1G backward compatible
  • Virtual Chassis stacking with Non-Stop Forwarding (NSF) and hitless failover
  • License-free Layer 2 switching and Layer 3 routing (static, RIP, OSPF, VRRP, PIM, PBR)
  • NETGEAR IGMP Plus™ for AV-over-IP deployments
