Included in the Box

1 x QuikSpot (AST-QUKSP)

1 x QuikSpot Yoke (AST-QUKSP-YK)

Technical Specifications

LED Engine: Titan LED Engine

Colors: RGBMintAmber

Output Gain: Yes

Total LED Power: 60 W

LED Power Draw: 38 W

CRI (Ra) / TLCI 3200 – 6500 K*: ≥96

Strobe: 0 – 25 Hertz

Battery Runtime: up to 20 hours

Battery Runtime (max. Brightness): 4.5 hours

Battery Lifetime: 70 % after 500 cycles

Charging Time (nominal): 5 hours

AC Input: 100 – 240 VAC, 50/60 Hertz 115 VAC – 0.6 A / 230 VAC – 0.3 A

AC Connector: PowerCON TRUE1 IN/OUT

Power Consumption (max.): 50 W

Wired DMX: Yes

CRMX Receiver: Built-in

BluetoothBridge BTB: Built-in

Wireless Protocols: CRMX, UHF, Bluetooth, WiFi

Wireless Range: CRMX/UHF up to 300 m / 330 yds Bluetooth up to 3 m / 3.3 yds

RDM Support: Wireless and wired

Infrared Control: Yes

PrepBox Compatible: Yes

IP Rating unwired: IP65

IP Rating wired: IP65

Ambient Operating Temperature: 0 – 40 °C / 32 – 104 °F

Weight: 3450 g

Dimensions (L x W x D): 164 mm x 164 mm x 182 mm / 6.45" x 6.45" x 7.16"

Mounting Options: AirlineTrack, 3/8"" – 16 UNC thread, Yoke (with 3/8"" – 16 UNC thread, 1/2"" hole)
