Technical Specifications

Description

SOURCE

  • Light source: 1x60W RGBW COB LED
  • LED Ring: 24 x 0.5 Watts RGB LEDs
  • LED life expectancy: 50,000 Hrs.

OPTICAL SYSTEM

  • Zoom: 5° – 45°
  • High Efficiency Lens

DYNAMIC EFFECTS

  • High Speed Zoom
  • Color mixing: RGBW
  • Electronic variable strobe
  • Built-in dynamic macros

CONTROL & PROGRAMMING

  • Control protocols: DMX
  • Display: LCD screen display
  • Control channels: 13, 18 CHs

CONNECTIONS

  • DMX connections: 3 pin Cable In/Out male and female
  • Power connections: Power Cable In/Out male and female

ELECTRICAL

  • Input voltage: 110-240V/50-60Hz
  • Power consumption: 80 watts

 PHYSICAL

  • Dimensions: 260 x 200 x 160mm
  • Net weight: 2.8 Kg
  • Color: Black
  • IP rating: 20
