Technical Specifications

Description

SOURCE

  • Light Source: 4 x 100 watts LED
  • Illuminance: 9,250 lux @ 1m
  • Color temperature: 3200k
  • LED Life Expectancy: 50,000 Hrs.

OPTICAL SYSTEM

  • Beam Angle: 50°
  • 4 Rotatable Heads

DYNAMIC EFFECTS

  • Dimmer: Linear adjustment
  • Electronic strobe: 1-30 Hz
  • 4 zones control

CONTROL & PROGRAMMING

  • Display: LCD Control Panel
  • Control Channels: 4, 8 CHs
  • Control Protocols: DMX, Auto, Sound

ELECTRICAL

  • Input Voltage:  100-240V/50-60Hz
  • Power Consumption: 450 W

CONNECTIONS

  • DMX Connections: On Cable 3 pin XLR In/Out
  • Power Connections: On Cable Waterproof 3 pin In/Out

PHYSICAL

  • Dimensions: 450 x 420 x 270mm
  • Net weight: 12 Kg
  • Color: Black
  • Housing: Aluminum
  • IP rating: IP65
