SOURCE

• Light Source: 36pcs x 10W WW (Warm White)
• Light Source (additional): 48pcs x 1W Red + 48pcs x 1W Amber
• Light Output: 10,209 lm

OPTICAL SYSTEM

• Beam Angle: 40°

COLOR

• Color Mixing: Red, Amber, and Warm White (WW) mixing

DYNAMIC EFFECTS

• Built-in Effects: Variable color chasing, strobing, and fading
• Special Effects: Halogen/Redshift effect (simulates halogen lamp behavior when dimming)
• Strobe Effect: Multiple strobe modes (opening/closing pulse, random strobe, burst pulse, random burst, and sine wave)

CONTROL & PROGRAMMING

• Display: TFT displayer with four buttons
• Control Channels: 1 / 4 / 6 / 12 / 16 / 21 / 24 / 34 CHs
• Control Protocols: DMX 512, Master/Slave, Auto Run, and RDM
• Dimming: 4 selectable dimming curves (Linear, Square Law, Inverse Square Law, S-Curve)
• Internal Programs: 5 Auto modes (Auto 1–5) and adjustable speed (01–05)
• LED Frequency: Selectable PWM ensuring video flicker-free
• PWM Frequency: Adjustable from 600Hz to 25,000Hz

THERMAL MANAGEMENT

• Operating Temperature: -20°C to 50°C
• Temperature Control: Working temperature displayed on-screen; includes color-coded alerts (yellow) when exceeding maximum temperature

CONNECTIONS

• Power Connections: Power-In and Power-Out (daisy-chain capable)
• DMX Connections: 3-pin XLR (DMX-In and DMX-Out)

ELECTRICAL

• Input Voltage: AC110 - 230V / 50 - 60Hz
• Power Consumption: 260W

PHYSICAL

• Dimensions: 1017 x 140 x 169 mm
• Net Weight: 9.5 Kg
• Housing: Aluminum
• IP Rating: IP65

INSTALLATION

• Mounting: Three positions: hanging (upside-down), flat level surface, or side-mounted
