Technical Specifications

Description

Specifications

  • Light source: 400W RGBALC
  • Optical system: 6" Fresnel lens
  • Beam angle: 9°-60° manual zoom
  • CRI/Ra: up to 98
  • Output: 12,000+ lumens

Dimensions & Weight

  • IP class: IP65
  • Dimensions incl. Yoke: 320 x 405 x 370 mm
  • Dimensions excl. Yoke: 238.5 x 276 x 370 mm
  • Net weight excl. Barndoor: 9 kg
  • Net weight incl. Barndoor: 10.5 kg
  • Operating temperature range: -40°C to 45°C

Electrical Data

  • Operating voltage: 100-240V 50/60Hz
  • Power Max. Out: 401W @ 230V / 414W @ 100V
  • Standby Power: 9.8W
  • Power Supply: Inbuilt auto-ranging electronic switch-mode

Control

  • DMX channels: 4-21 CH
  • Protocol: USITT DMX512A, RDM ANSI E1.20; optional CRMX, W-DMX™ G2-G4S, Bluetooth (Low Energy); KLSTR technology ready
  • Wireless DMX: Optional LumenRadio (CRMX)

Installation

  • Orientation: Any | Rigging: Hanging direct
  • Safety features: 1x safety eye
  • Minimum distance from flammable materials: 0.3 meters
