AQUARAY X5 - 620W Lamp Moving Head

Aquaray-X5

Aquaray-X5

The Aquaray X5 is a powerful Lamp Moving Head fixture engineered for high-intensity beam and spot applications. Driven by a robust OSRAM 420W lamp, this fixture delivers an immense 330,000 lux at 10 meters and a razor-sharp $2. 2^{\circ}$ beam angle, making it ideal for large-scale and demanding projects. Its intelligent design features professional dynamic effects, including 14 colors, combinable 8-facet and 24-facet rotating prisms, and a versatile static gobo wheel with beam shapers. Built with a smooth 16-bit movement (540° Pan / 270° Tilt) and an IP44-rated structure, the Aquaray X5 is a reliable, high-quality tool for creative lighting in challenging professional event environments.

SKU: AQUARAYX5 Categories: Lamp Moving Heads, Lighting Brand: Cyclops Lighting

Description
Downloads

Product Description

SOURCE

Lamp: OSRAM 420W
CTO: 7700K
Light source life: 3000 hours
Output: 12500 lm
Illuminance: 330000 lux @ 10meters
Power: 620W
Power Factor: PF＞0.95

OPTICAL SYSTEM

Beam angle: 2.2°
Electronic focus

DYNAMIC EFFECTS

Dimmer: Linear adjustment
Color wheel: 14 colors+white light
Static gobo: 6 gobos + 5 beam shapers + 4 colored glass gobos
Effect wheel: Color effect wheel
Prism: 2 rotatable and combinable prisms: 8-facet circular + 24-facet circular
Strobe: Variable strobe + macros

CONTROL & PROGRAMMING

Display: 1.7 inches TFT display, reversible 180°
Control channels: 16, 20 Chs

MOVEMENT

Pan: 540°
Tilt: 270°
Resolution: 16 bit

ELECTRICAL

Input voltage: 100-240V/50-60Hz
Current: 4A-1.85A
Power consumption: 620W

CONNECTIONS

DMX connections: 3 pin and 5 pin XLR In/Out male and female
Power connections: PowerCon In/Out male and female

PHYSICAL

Dimensions: 370×335×610mm
Gross weight: 25 Kg
Net weight: 23 Kg
Color: Black
IP rating: IP44
