SPARKLY 1400P - High Power Profile Moving Head 1400 Watts

SPARKLY 1400P is a 1400 watts moving head profile. It features a CMY color mixing, four rotatable DMX controlled shutter blades and a wide zoom range from 6 to 51 degrees. With a CTO filter to tweak the white color temperature and high CRI output of 95, this moving head profile perfectly fits all theatrical and studio applications, as well as concert and band events. The powerful and sharp output is shaped with a set of static and interchangeable rotatable gobos and a rotatable prism for a wide variety of patterns and designs.

Product Description

SPARKLY 1400P is a 1400 watts moving head profile. It features a CMY color mixing, four rotatable DMX controlled shutter blades and a wide zoom range from 6 to 51 degrees. With a CTO filter to tweak the white color temperature and high CRI output of 95, this moving head profile perfectly fits all theatrical and studio applications, as well as concert and band events. The powerful and sharp output is shaped with a set of static and interchangeable rotatable gobos and a rotatable prism for a wide variety of patterns and designs.

SOURCE

  • Light source: Osram Lok-it 1400 watts
  • Lamp life expectancy: 750 Hrs.
  • CRI > 95

OPTICAL SYSTEM

  • Beam angle: 6° to 51°
  • Four shutter blades, 180° rotatable
  • Electronic focus, 16 bit
  • 140mm diameter front lens
  • Iris

DYNAMIC EFFECTS

  • Dimmer: 16 bit linear adjustment
  • Color mixing: CMY
  • Color wheel: 7 colors + white
  • CTO filter, 3200K to 6000K
  • Static gobo: 8 gobos + open
  • Rotating gobo: 6 gobos + open
  • Prism: 4 facet prism
  • Frost

CONTROL & PROGRAMMING

  • Control protocols: DMX, Master Slave, Auto Run
  • Display: 3.5′  color LCD display, reversible 180°
  • Control channels: 37, 41 CHs

MOVEMENT

  • Pan: 540o
  • Tilt: 270o
  • Resolution: 16 bit

ELECTRICAL

  • Input voltage: 200-240V/50-60Hz
  • Power consumption: 1800 watts

CONNECTIONS

  • DMX connections: 3 pin and 5 pin XLR In/Out male and female
  • Power connections: Powercon In

PHYSICAL

  • Dimensions: 482 x 372 x 870mm
  • Net weight: 40.5 Kg
  • Color: Black
  • IP rating: 20

Download

Data Sheet
