Event 210A - 3-Way Powered Line Array

The EVENT-210A Line is a three-way powered line array in a double 10” “dual-band” configuration which provides a wider frequency range. The DAS loudspeaker units has been teamed up with a single M-75 compression driver and purpose-designed injected aluminum high frequency waveguide.

The EVENT-210A line array is powered by a three channel Class D amplifier which provides 360 Wpeak per channel. The amp´s rear panel includes quality Neutrik® XLR and powerCON connectors, status LEDS to facilitate setup and DAS’s Easy-DSP™ interface which simplifies preset selection for the number of units and throw depth.

Product Description

Key Features

  • Powered 3-way system
  • Light-weight Class D amplifier topology
  • Easy-DSP™ Interface
  • Durable ISO-flex finish
  • Robust “quick-rig” professional rigging hardware
  • Proprietary injected aluminium HF waveguide
  • DAS M-75 compression driver and cone transducers

Applications

  • House of worship
  • Theatres, auditoria and performing arts centers
  • Live music clubs
  • Live sound touring/Rental services

Technical Data

  • Nominal HF Amplifier Power: 360 Wpeak
  • Nominal MF Amplifier Power: 360 Wpeak
  • Nominal LF Amplifier Power: 360 Wpeak
  • Frequency Range (-10 dB): 70 Hz -20 kHz
  • Rated Peak SPL at 1 m: 134 dB
  • Horizontal Coverage (-6 dB): 90º Nominal
  • Vertical Coverage: Splay Dependent
  • Enclosure Material: Birch Plywood
  • Color/Finish: Black ISO-Flex Paint
  • Connectors: INPUT: Female XLR | LOOP THRU: Male XLR | AC INPUT: powerCON | AC OUTPUT: powerCON
  • AC Requirements: 115 V, 3.0A, 50 Hz/60 Hz | 230 V, 1.5A, 50 Hz/60 Hz
  • Dimensions (H x W x D): 27 x 73 x 36.6 cm | 10.6 x 28.7 x 14.4 in
  • Weight: 34 kg (74.8 lb)
