Kommander - KA04 Compact Amplifier and Processing Solution

Product Description

GENERAL

• Type: 4ch switching mode, Class D Amplifier
• Output Power: 4x 50 W @ 4 Ω
• Impedance: minimum 4 Ω
• Frequency Response: 20 Hz – 20 kHz (±1 dB)
• Connectors:

  Input:
  4x BAL input: Euroblock 1.5/ 3-ST-3.81,
  3.5 mm jack unBAL analog stereo AUX input,
  TOSLINK optical input,

  Output:
  2x Euroblock 2,5/ 4-G-5,08

  Digital:
  4x USB-A 2.0,
  1x RJ45 Ethernet,
  Bluetooth 4.1 Low Energy,
  Wi-Fi IEEE 802.11 b/g/n

  Power:
  1x PowerCon TRUE IN

• Built-in DSP: Grouping, Input EQ, Output EQ, Signal Routing, Level adjustment, Dynamic Limiters, Delay
• Remote control: Wi-Fi dedicated K-array Connect mobile app. Ethernet wired K-framework3 multiplatform design and tuning software
• Protections: Over Temp. (Power Limiting – Thermal Shutdown), Short Circuit/Overload Output Protection, Power Limiting, Clip Limiter/Permanent Signal Limiter, High Frequency Protection
• MAINS Operating Range: 100-240V ~ AC, 50-60 Hz with PFC
• Power Consumption: 150 W @ 4 Ω load, Pink noise, 1/8 rated power

Handling and Finishes

• IP Rating: IP20

• Dimensions (W x H x D): 219 x 46 x 320 mm (8.6 x 1.8 x 12.6 in)

• Weight: 1.2 kg (2.65 lb)

• Material: Aluminum
