MFP31 - Portable Multi-Format Presentation Switch

Product Description

Key Features

• Features 1 x HDMI, 1 x USB-C and 1x Mini DisplayPort™ input which can be switched to a single HDMI output
• Supports HDMI 2.0 18Gbps specification including HDR
• Supports resolutions up to 4K UHD 60Hz 4:4:4
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Supports Mini DisplayPort™ up to 4K UHD 60Hz 4:4:4, DP1.2
• Supports USB Type C up to 4K UHD 60Hz 4:4:4, DP1.2
• Supports both manual or automatic source selection
• HDCP 2.2 compliant

Specifications

• Video Input Connectors: 1 x HDMI Type A, 19-pin, female, 1 x USB-C Type C, 1 x Mini DisplayPort™
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female
• Local power input: 1 x Micro USB, female
• Casing Dimensions (Dia x H): 105mm x 25mm
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: 5V/1A DC

Box Contents

• 1 x MFP31
• 1 x 5V/1A DC Power Supply
• 1 x USB to Micro-USB Charging Cable
• 1 x Quick Reference Guide
• 1 x Cloth Bag
