MSD600 - LED Sending Card (4 Gigabit Ethernet Outputs)

The MSD600 is a sending card developed by NovaStar. It supports 1x DVI input, 1x HDMI input, 1x audio input, and 4x Ethernet outputs. A single MSD600 supports input resolutions up to 1920×1200@60Hz.
The MSD600 communicates with PC via type-B USB port. Multiple MSD600 units can be cascaded via UART port.
As a highly cost-effective sending card, the MSD600 can be mainly used in the rental and fixed installation applications, such as concerts, live events, security monitoring centers, Olympic Games and various sports centers

Brand: NovaStar

Add to Quote

SKU: MSD600 Brand: PRCM

Description
Download

Product Description

Key Features:

3 types of input connectors
− 1x SL-DVI
− 1x HDMI 1.3
− 1x AUDIO
4x Gigabit Ethernet outputs
1x light sensor connector
1x type-B USB control port
2x UART control ports
They are used for device cascading. Up to 20 devices can be cascaded.
Pixel level brightness and chroma calibration
Work with NovaStar’s high-precision calibration system to calibrate the brightness and chroma of each pixel, effectively removing brightness differences and chroma differences, and enabling high brightness consistency and XI’AN chroma consistency.
