PRO-IN2H2TCS - 4-Way HDMI 2.0 & HDBaseT™ CSC Input Board

Product Description

Key Features

• Features 2 x HDMI and 2 x HDBaseT™ inputs which can be independently routed to video output cards

• HDMI and HDBaseT™ inputs support HDMI 2.0 18Gbps specification including up to 4K UHD 60Hz 4:4:4 and HDR resolutions*

• HDBaseT™ inputs support signal distribution up to a distance of 100m @ 1080p (4K 60Hz 4:4:4 UHD @ 70m) when used with a compatible Blustream CSC Transmitter**

• Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission

• Each HDMI / HDBaseT™ input includes an independent fixed level 2ch analogue audio breakout allowing connection to a local third party audio solution (supports 2ch PCM)

• HDBaseT™ inputs include IR distribution to allow source control at each connected HDBaseT™ Transmitter

• Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub

• HDCP 2.2 Support

  *Full 4K 60Hz 4:4:4 support is subject to input / output boards specified. For HDMI 2.0 18Gbps video distribution the PRO-IN2H2TCS must be used with a Blustream CSC based HDBaseT™ Transmitter


  **The PRO-IN2H2TCS does not support PoC (Power over Cable) to connected Blustream HDBaseT™ Transmitter units. A separate power supply unit must be specified

Specifications

• Video Input Connectors: 2 x HDMI Type A, 19-pin, female, 2 x HDBaseT™ RJ45 connector

• Audio Output Connectors: 4 x Analogue Left/Right audio (3.5mm stereo jack)

• IR Input Ports: 2 x 3.5mm stereo jack

• Card Dimensions (W x H x D): 170mm x 22mm x 182mm

• Dimensions Including Connections (W x H x D): 190mm x 22mm x 188mm

• Shipping Weight: 0.5kg

• Operating Temperature: 32°F to 104°F (0°C to 40°C)

• Storage Temperature : -4°F to 140°F (-20°C to 60°C)
