Safety Socket DIN 63A 4p 6h IP67 Twist

Product Description

HOUSING MATERIAL:

• PC/ABS

RATED CURRENT:

• 63A

NUMBER OF POLES

• 4 (3P+PE)

CLOCK-POSITION

• 6h

RATED VOLTAGE/FREQUENCY

• 380-415V~ / 50+60Hz

CONTACTS

• brass, with lamellar spring (CuBe)

CONNECTION TECHNOLOGY

• screw terminals
• wall mounting, mechanical interlock, hinged
  window (6 modules), DIN-rail

SWITCH

• ON/OFF PCE-Merz ML2-063; EN 60947-3;
  AC22A, 10kA

CABLE ENTRY

• top, bottom or rear (incl. threaded
  blind cap)

IP PROTECTION CLASS

• IP66/IP67
