UEX3D- USB 3.2 Gen1 HDBaseT™ Extender - Device

Product Description

Key Features

• USB 3.2 Gen1 HDBaseT™ Extender supporting 2 x USB Host devices and 2 x local USB Devices
• Supports USB 3.2 signal extension up to 100m over HDBaseT™ *
• Backwards compatible with USB 2.0 & 1.1 devices
• Combined USB3.2 Gen1 data transfer rate up to 5Gbps *
• 2 x USB-A & 2 x USB-C port for connection to local devices
• Provides up to 3A combined power to USB devices (up to 1.7A per single USB port)
• Configurable USB device power management via API commands
• Bi-directional PoC (Power over Cable) to power extenders from either the host or device unit (supports 12-48V PoC)
• Supports bi-directional RS-232 when used with compatible HDBaseT™ products
  PoC function can be enabled/disabled via dipswitch
• Simple plug and play, no driver installation or setup required

Specifications

• CAT Connectors: 1 x RJ45 connector
• USB Device Ports: 2 x USB Type C female, 2 x USB Type A female
• Local power input: 1 x 2-Pin Phoenix connector
• Firmware Upgrade: 1 x Micro-USB
• RS-232: 1 x 3-Pin Phoenix connector
• Power Supply: 24V/1.5A DC
• Dimensions (W x D x H ): 133mm x 105mm x 22mm
• Shipping Weight: 1.0kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature : -4°F to 140°F (-25°C to +70°C)

Box Contents

• 1 x UEX3D
• 1 x 24V/1.5A power supply
• 1 x RS-232 control cable (3-Pin to DB9)
• 1 x Quick Reference Card
