ZOOM 19 MK ll – LED Wash Moving Head

ZOOM 19 II is a compact and rapid moving head wash fixture that produces a bright, powerful light. It has a light output of over 52,700 Lux and incredible peak intensity of more than 173,000 cd combined with a versatile 8° to 40° zoom. This LED wash moving head is ideal for indoor applications such as theaters, nightclubs, churches and concert halls.



SKU: ZOOM19II Categories: , , Brand:

Product Description

ZOOM 19 II is a compact and rapid moving head wash fixture that produces a bright, powerful light. It has a light output of over 52,700 Lux and incredible peak intensity of more than 173,000 cd combined with a versatile 8° to 40° zoom. This LED moving wash is ideal for indoor applications such as theaters, nightclubs, churches and concert halls.

SOURCE

  • Light source: 19 x 15 watts OSRAM multi-chip RGBW
  • Lamp life expectancy: 2,000 Hrs.

OPTICAL SYSTEM

  • Beam angle: 8° to 40°
  • Light output: 52,700 Lux @ 2m @ 8°
  • Lumen output: 4250 lm
  • Peak intensity: 173,000 cd

DYNAMIC EFFECTS

  • Dimmer: Linear adjustment
  • Color mixing: RGBW
  • Strobe: 0-20Hz
  • Ring control
  • Built-in color and dynamic macros

CONTROL & PROGRAMMING

  • Control protocols: DMX
  • Control channels: 10, 21, 8, 21, 34 CHs

MOVEMENT

  • Pan: 540 °
  • Tilt: 300 °
  • Resolution: 16 bit

ELECTRICAL

  • Input voltage: 100-240V/50-60Hz
  • Power consumption: 350 watts

CONNECTIONS

  • DMX connections: 3 pin and 5 pin XLR In/Out male and female
  • Power connections: PowerCon In/Out

PHYSICAL

  • Dimensions: 322 X 258 X 341mm
  • Net weight: 10 Kg
  • Color: Black
  • Housing: Flame retardant plastic, aluminum cast
  • IP rating: 20
  • Operation temperature: 20°C/45°C

Download

Data Sheet
