Truffle-KTR24 - Passive Subwoofer

TRUFFLE KTR24
TRUFFLE KTR24
...

The Truffle-KTR24 is the smallest model in the compact line of Truffle subwoofer. The source subwoofer has a frequency range of 45 Hz to 150 Hz. Easy to conceal, the Truffle-KTR24 is a 8″-long cylindrical speaker box equipped with one 4″ active driver on one end and one 4″ passive speaker on the other, making the box a perfect omnidirectional low-end source.

This subwoofer provides the low-end frequencies for the Azimut-KAMUT2L1 audio system.

SKU: KTR24 Categories: , Brand: Series:

Product Description

General:

  • Type: Passive subwoofer
  • Transudcers: 4″ woofer + passive radiator
  • Frequency Response : 45 Hz – 150 Hz (-6 dB)
  • Maximum SPL : 112 dB (peak)
  • Rated Power: 60 W
  • Coverage: Omni
  • Connectors: 2PIN euroblock connector (included)
  • Nominal Impedance: 4 Ω

Handling and Finishes:

  • Dimensions (W x H x D): 122 x 117 x 199 mm (4.8 x 4.6 x 7.8 in)
  • Weight: 1,5 kg (3.31 lb)
  • Material: Aluminum
  • Color: Black
  • Finishes: Powder Matte

Regulations:

  • IP Rating: IP64

Additional information

Weight 1.5 kg
Dimensions 19.9 × 12.2 × 11.7 cm

Downloads

Data Sheet
